Sunming Newtop
24" Gas Griddle SML-G24
24" Gas Griddle SML-G24
Newtop 24" Gas Griddle SML-G24
Available in 12", 24“, 36”,48“ & 60” widths, the 30,000 BTU output per burner provides even heat to the 3/4“ thick polished steel griddle plate. Adjustable manual gas controls provide easy and safe operations. Pilot light can be lit from the front for ease of use.
Standard Features
- “U” shape burners provide even heat distribution every 12”
- 3/4“ griddle plate
- 30,000 BTU / burner
- Gas control knob every 12”
- All stainless steel cabinet
- Double wall insulated sides
- “Cool-to-the-touch” front s/s edge
- Back and side splash guards fully welded to griddle plate
- Flue located on back of unit for ample ventilation
- Adjustable stainless steel legs, non-skid feet
- Each Griddle shipped standard Natural gas, LP conversion kit included
- Easy to remove 3-1/4” grease drawer with
- Grease trough is standard 4” spatula width
- Griddle is fully serviceable from the front
Product Specification
- Controls: Manual
- Number of Burners: 2
- BTUs: 30,000 per burner, total 60,000
- Cooking Area: 20.5”D x 24”W
- Overall Dimensions: 34.4’’L x 24’’W x 15.5’’H (87.3 cm x 61.0 cm x 39.4 cm)
- Weight: 144 lbs (71.0 kg)
- Shipping Dimensions: 36.2’’ L x 28.3’’ W x 19.3’’H (92 cm x 72 cm x 49 cm)
- Shipping Weight: 196 lbs (89.0 kg)
